Description
N 90 canopy cooker hood 70 cm clear glass black printed
Canopy hood: designed to fit neatly under an overhead unit or cabinet. They're discreet and effectively use valuable space.
- EfficientDrive: save energy and enjoy a quieter kitchen thanks to efficient brushless motor technology
- Intensive speed setting: increases the extraction rate when the steam gets intense
- Dimmer Function – easily dim the light according to your mood with the touch of a finger
- Interval Ventilation – automatically ventilates every hour for crisp, clean air
- Automatic After-running – ventilation continues for several minutes after you turn it off
Technical Specification
Key performance features:
- Energy Efficiency Class: A++ (at a range of energy efficiency classes from A+++ to D)
- Extraction rate according to EN 61591 ø 15 cm:
max. Normal use 575 m³/h
Intensive 775 m³/h - Noise max. Normal Level: 64 dB*
Features
- LED display
- Soft touch control
- 3 speeds plus intensive
- Automatic intensive revert (6mins)
- 2 x 1W LED lights
- softLight with dimmer function
- Interval operation
- EfficientDrive BLDC technology
- Automatic after running (30 mins)
- 2 metal grease filter cassettes
- Saturation indicator for grease filter
Design
- Canopy hood
- For installation in a kitchen cabinet
- Filter cover glass, metal grease filter
- Electronic controls
- Suitable for ducted extraction and recirculation
- For recirculated extraction recirculating kit or CleanAir recirculating kit (accessory) needed
- Extraction rate according to EN 61591 max. 575 m³/h
- Noise level according to EN 60704-3 and EN 60704-2-13 at max. normal use exhaust air: 64 dB(A) re 1 pW
- Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
Max. normal use: 64 dB(A) re 1 pW
Intensive: 70 dB(A) re 1 pW - With the Clean Air Plus recirculation kit (available as optional accessory) your appliances reaches:
Extraction rate in recirculation mode:
Max. normal use: 533 m³/h
Intensive: 722 m³/h
Noise level in recirculation mode:
Max. normal use: 71 dB(A) re 1 pW
Intensive: 77 dB(A) re 1 pW - Power rating: 172 W
- Light Intensity: 244 lux
- Colour Temperature: 4000 K
- Electrical cable length 1.5 m
- Blower Efficiency Class: A*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: D*
- Average Energy Consumption: 30.3 kWh/year*
- Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
- Dimensions exhaust air (HxWxD): 418-418 x 700 x 300 mm
