For recirculated extraction recirculating kit or CleanAir recirculating kit (accessory) needed
Extraction rate according to EN 61591 ø 15 cm: max. Normal use 427 m³/h Intensive 702 m³/h
Maximum extraction rate exhaust air 427 m³/h according to EN 61591
Noise level according to EN 60704-3 and EN 60704-2-13 at max. normal use exhaust air: 55 dB(A) re 1 pW
Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air: Max. normal use: 55 dB(A) re 1 pW Intensive: 66 dB(A) re 1 pW
With the Clean Air Plus recirculation kit (available as optional accessory) your appliances reaches: Extraction rate in recirculation mode: Max. normal use: 343 m³/h Intensive: 442 m³/h Noise level in recirculation mode: Max. normal use: 66 dB(A) re 1 pW Intensive: 70 dB(A) re 1 pW
Power rating: 145 W
Light Intensity: 359 lux
Colour Temperature: 3500 K
Average Energy Consumption: 33.6 kWh/year*
Blower Efficiency Class: A*
Lighting Efficiency Class: A*
Grease Filtering Efficiency Class: B*
Electrical cable length 1.3 m
Dimensions recirculating with CleanAir module (HxWxD): 689 x 898 x 500 mm - mounting with outer chimney 795-1139 x 898 x 500 mm - mounting with telescopic chimney
Additional noise insulation
Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
Max. extraction rate: 702 m3/h
Dimensions exhaust air (HxWxD): 614-954 x 898 x 500 mm
Dimensions recirculating (HxWxD): 614-1064 x 898 x 500 mm
