Description
Compact Smart Radio
Compact Smart Radio with DAB+, Internet Radio, FM-RDS, Spotify Connect, Bluetooth, USB and TFT Colour-Display. Additionally you can listen to your favourite music via Bluetooth or Spotify Connect.
Key Features:
- DAB+ FM RDS Tuner
- Internet Radio
- Bluetooth Audio Streaming
- Spotify Connect
- USB and Line-In (3,5mm jack) inputs
- Large TFT color display
- Clock function including Dual-Alarm and Sleeptimer
- WiFi 802.11a/b/g/n (2.4GHz/5GHz)
- 2 x 10W RMS Bassreflex Speaker-System
- Bassreflex Stereo Speaker
- 20 station presets / 10 Spotify presets
- Remote Control via UNDOK App
- IR-Remote Control
Tuner Features:
- Tuner Yes, FM with RDS
- Tuner (DAB+)
- Radio Data System
- Radio Text
- PTY (FM)
- PTY (DAB)
- DLS (DAB)
Amplifier Features:
- Maximum Stereo Output Power:2 x 10 Watt
Speakers:
- Type:2 x 3"(7,62 cm) Speaker
- Configuration:Full Range Bass Reflex System
- Grill:Fixed Metal Grill
USB Features:
- Playable Files:MP3
- Compatible Media:Mass Storage Device
- Repeat Playback:Titel / Folder / All
- Random Playback:Yes
Network Specifications:
- Wi-Fi IEEE Standard:IEEE 802.11
- Wi-Fi Protocol:a / b / g / n
- Wi-Fi Security Encryption:WEP, WPA, WPA2 (PSK), WPS
- Wi-Fi Frequency Range:2.412 - 2.472 GHz
- Wi-Fi Frequency Range:5.18 - 5.32 GHz
- Wi-Fi Frequency Range:5.5 - 5.7 GHz
- Wi-Fi Frequency Range:5.745 - 5.825 GHz
- Wifi Output Power WiFi 2,4G:15.94 dbm
- Wifi Output Power WiFi 5G:14.03 dbm
- Wifi Output Power WiFi 5,8G:10.24 dbm
Specification:
| General | |
|---|---|
| Brand | Kenwood |
| Colour | White |
| Display | Yes |
| Power Source | Mains |
| Connectivity | |
| Headphone Jack | Yes |
| Aux input | Yes |
| USB | Yes |
| Bluetooth | Yes |
| Wi-Fi | Yes |
| Functions | |
| Radio Tuner | DAB+, FM with RDS, PTY (DAB), PTY (FM), DLS (DAB) |
| Alarm Function | Yes |
| Clock | Yes |
| Dimensions | |
| Width (mm) | 245 |
| Depth (mm) | 115 |
| Height (mm) | 145 |
| Weight (kg) | 1.7 |
| Main | |
| Warranty | 2 Years |
| More | |
| Remote Control | 31-key Slim Type Remote |
| Remote Control App | Yes, (UNDOK App) |
| Maximum Practical Power | 2 x 10 Watt |
| FM Tuning Frequency Range (MHz) | 87.5 ~ 108 |
| DAB+ Tuning Frequency Range | 174,928 MHz ~ 239,200 MHz (Band III) |
| Format | USB Host (Playback) |
| USB Standard | 1.1 Full Speed |
| Compatible Files | MP3 files with file extension <.mp3> |
| MP3 Bitrate (CBR/VBR) | 32 kbps to 320 kbps |
| Maximum Current Supply (mA) | 500 |
| File System | FAT 16 / 32 |
| Display Type | 6.1cm high TFT color display |
| Bluetooth Version | 4.2 |
| Advanced Audio Distribution Profile (A2DP) | Yes |
| Audio/Video Remote Control Profile (AVRCP) | Yes |
| Output Power (dBm) | 7.9 |
| Maximum Service Area | About 10m (Communication range may vary depending on the enviromental conditions) |
| Frequency Band (GHz) | 2.402 - 2.480 |
| Stand-by Power Consumption (less than) | 0.9 Watt |
| Power Supply | 100-240V AC 50/60Hz |
| DC Output | 12V / 2A / 24W |
| Operational Temperature Range (°C) | 0 - 35 |
| USB-A Terminal (USB Host) | Yes |
| Auxiliary Input Jack (3.5mm) | Yes |
| Output Jack (3.5mm) | Yes |
